Input Impedance: 1MΩ
Output Impedance: 1 kΩ
Maximum Output Level: +8dBV
Noise Floor*: -96 dBV
Delay Time: 40ms to 1200ms
Noise Reduction: 2:1 ratio
Modulation Speed: 0.1 Hz to 10 Hz
Tap Divisions: Dotted 8th, 8th, Triplet, 16th
Bright**: 1.5 kHz, +4.5 dB, 200 Hz, -3 dB
Bypass: True Hardwire
Current Draw: 22 mA***, 44 mA****
Power Supply: DC 9 volts
*A-weighted, MIX control Full CW, REGEN control Full CW, Internal INPUT GAIN to GTR position.
** Delayed Signal
*** All selectable LEDs OFF, Delay control CW to 9 o’clock
****All selectable LEDs ON, Delay control 9 o’clock to CCW
