BODY MATERIAL: Ash
BODY FINISH: Satin
BODY SHAPE: Dinky®
NECK
NUMBER OF STRINGS: 6
NECK MATERIAL: Maple
NECK CONSTRUCTION: Bolt-On with Graphite Reinforcement and Scarf Joint
NECK BINDING: Black - Headstock Only
NECK FINISH: Satin
SCALE LENGTH: 25.5" (64.77 cm)
FINGERBOARD MATERIAL: Ebony
FINGERBOARD RADIUS: 12"-16" Compound Radius (304.8 mm to 406.4 mm)
NUMBER OF FRETS: 24
FRET SIZE: Jumbo
NUT MATERIAL: Floyd Rose® 1000 Series Locking
NUT WIDTH: 1.6875" (42.86 mm)
POSITION INLAYS: Offset Pearloid Dot
SIDE DOTS: Black
TRUSS ROD: Dual-Action with Wheel
TRUSS ROD NUT: Heel-Mount Truss Rod Adjustment Wheel
ELECTRONICS
BRIDGE PICKUP: Seymour Duncan® JB™ TB-4
NECK PICKUP: Seymour Duncan® '59™ SH-1N
CONTROLS: Volume, Tone
SWITCHING: 5-Position Blade: Position 1. Bridge Full Humbucker, Position 2. Bridge Inner Coil, Position 3. Both Inner Coils, Position 4. Neck Inner Coil Position 5. Neck Full Humbucker
CONFIGURATION: HH
HARDWARE
BRIDGE: Floyd Rose® 1000 Series Double-Locking Tremolo (Recessed)
HARDWARE FINISH: Black
TUNING MACHINES: Jackson® Sealed Die-Cast
CONTROL KNOBS: Dome-Style
SWITCH TIP: Black
NECK PLATE: 4-Bolt (recessed screws)
