BODY MATERIAL: Poplar
BODY FINISH: Satin
BODY SHAPE: Dinky®
NECK
NUMBER OF STRINGS: 7
NECK MATERIAL: Maple
NECK CONSTRUCTION: Bolt-On with Graphite Reinforcement and Scarf Joint
NECK FINISH: Satin
SCALE LENGTH: 25.5" - 27" Multi-Scale (648 mm - 686 mm)
FINGERBOARD MATERIAL: Laurel
FINGERBOARD RADIUS: 12"-16" Compound Radius (304.8 mm to 406.4 mm)
NUMBER OF FRETS: 24
FRET SIZE: Jumbo
NUT MATERIAL: Black Plastic
NUT WIDTH: 1.875" (47.6 mm)
POSITION INLAYS: Offset Pearloid Dot
TRUSS ROD: Dual-Action
TRUSS ROD NUT: Truss Rod Adjustment at Nut
ELECTRONICS
BRIDGE PICKUP: Jackson® Uncovered 7-String Blade Humbucking
NECK PICKUP: Jackson® Uncovered 7-String Blade Humbucking
CONTROLS: Volume, Tone
SWITCHING: 3-Position Toggle: Position 1. Bridge Pickup, Position 2. Bridge And Neck Pickups, Position 3. Neck Pickup
CONFIGURATION: HH
HARDWARE
BRIDGE: Staggered Individual Saddles
HARDWARE FINISH: Black
TUNING MACHINES: Jackson® Sealed Die-Cast
CONTROL KNOBS: Dome-Style
SWITCH TIP: Black
NECK PLATE: 4-Bolt (recessed screws)
