NECK MATERIAL: Maple
NECK FINISH: Satin Urethane Finish on Back of Neck with Gloss Urethane Headstock Face
NECK SHAPE: "C" Shape
NECK CONSTRUCTION: Bolt-On
FINGERBOARD RADIUS: 9.5" (241 mm)
FINGERBOARD MATERIAL: Indian Laurel
POSITION INLAYS: Pearloid Dot
SIDE DOTS: White
NUMBER OF FRETS: 21
TRUSS ROD: Head Adjust
STRING NUT: Synthetic Bone
NUT WIDTH: 1.650" (42 mm)
NUT MATERIAL: Synthetic Bone
BODY: Poplar
BODY FINISH: Gloss Polyurethane
BODY SHAPE: Stratocaster®
BODY TOP: Quilt Maple Veneer
BODY MATERIAL: Poplar
BRIDGE: 2-Point Synchronized Tremolo with Block Saddles
PICKGUARD: 4-Ply White Pearloid
PICKUP COVERS: White
CONTROL KNOBS: White
SWITCH TIP: White
HARDWARE FINISH: Chrome
TUNING MACHINES: Sealed Die-Cast with Split Shafts
STRING TREES: Dual-Wing
STRINGS: Nickel Plated Steel (.009-.042 Gauges)
TREMOLO ARM: Standard
NECK PLATE: 4-Bolt Squier®
STRAP BUTTONS: Standard
Electronics
BRIDGE PICKUP: Ceramic Single-Coil
MIDDLE PICKUP: Ceramic Single-Coil
NECK PICKUP: Ceramic Single-Coil
PICKUP CONFIGURATION: SSS
CONTROLS: Master Volume, Tone 1. (Neck/Middle Pickups), Tone 2. (Bridge Pickup)
SWITCHING: 5-Position Blade: Position 1. Bridge Pickup, Position 2. Bridge and Middle Pickup, Position 3. Middle Pickup, Position 4. Middle and
eck Pickup, Position 5. Neck Pickup
