Width: 1,450 mm [57-1/16"] Polished finish: 1,455 mm [57-5/16"]
Height: 927 mm [36-1/2"] (with music rest raised: 1,083 mm [42-5/8"]) Polished finish: 930 mm [36-5/8"] (with music rest raised: 1,084 mm [42-11/16"])
Depth: 460 mm [18-1/8"] Polished finish: 460 mm [18-1/8"]
Weight: 57 kg [125 lb, 11 oz]
Number of Keys: 88
Type: GrandTouch-S™ keyboard: synthetic ebony and ivory key tops, escapement
Touch Sensitivity: Hard2, Hard1, Medium, Soft1, Soft2, Fixed
Number of Pedals: 3: Damper (with half-pedal function), Sostenuto, Soft
GrandTouch Pedals: Yes
Assignable Functions: Sustain (Switch), Sustain (Continuous), Sostenuto, Soft, Pitch Bend Up, Pitch Bend Down, Rotary Speed, Vibe Rotor, Song Play/Pause
Display Type: Full Dots LCD
Language: English, Japanese
Panel Type: Buttons
Panel Language: English
Key Cover Style: Sliding
Music Rest: Yes
Music Braces: Yes
Voices:
Tone Generator:
Piano Sound: Yamaha CFX, Bösendorfer Imperial
Binaural Sampling: Yes (“CFX Grand” and “Bösendorfer” only)
Virtual Resonance Modeling (VRM): Yes
Grand Expression Modeling: Yes
Polyphony: Number of Polyphony (Max.): 256
Preset: Number of Voices: 38
Effects:
Types:
Reverb: 7 types
Chorus: 3 types
Brilliance: 7 types + User
Insertion Effect: 12 types
Intelligent Acoustic Control (IAC): Yes
Stereophonic Optimizer: Yes
Functions:
Dual/Layers: Yes
Split: Yes
Duo: Yes
Songs: Preset:
Number of Preset Songs: 23 Voice Demo + 50 Classics + 303 Lesson Songs
MIDI Recording:
Number of Songs: 250
Number of Tracks: 16
Data Capacity: Approx. 500 KB/Song (approx. 22,000 notes)
Audio Recording (USB flash drive):
Recording Time (max.): 80 minutes/Song
Compatible Data Format:
Playback: SMF (Format 0, Format 1), WAV (44.1 kHz, 16-bit, stereo)
Recording: SMF (Format 0), WAV (44.1 kHz, 16-bit, stereo)
Functions:
Piano Room: Yes
Rhythm:
Number of Rhythms: 20
Overall Controls:
Metronome: Yes
Tempo Range: 5 – 500
Transpose: −12 – 0 – +12
Tuning: 414.8 – 440.0 – 466.8 Hz (approx. 0.2 Hz increments)
Scale Type: 7 types
USB Audio Interface: 44.1 kHz, 24 bit, stereo
Bluetooth: Audio, MIDI (varies by area)
Storage and Connectivity:
Storage:
Internal Memory: Total maximum size approx. 1.4 MB
External Drives: USB flash drive
Connectivity:
Headphones: Standard stereo phone jack (× 2)
AUX IN: Stereo mini jack
AUX OUT: Standard phone jack (L/L+R, R)
USB TO DEVICE: Type A
USB TO HOST: Type B
DC IN: 16 V
Amplifiers and Speakers:
Amplifiers: 30 W × 2
Speakers: 16 cm with diffuser × 2
AC Adaptor: PA-300C
Power Consumption: 18 W (When using PA-300C AC adaptor)
Auto Power Off: Yes
