Size/Weight
Width: 1,420 mm (55-15/16") (Polished finish: 1,423 mm (56-0"))
Height: 868 mm (34-3/16") (Polished finish: 871 mm (34-5/16"))
Depth: 592 mm (23-5/16") (Polished finish: 593 mm (23-3/8"))
Weight: 82 kg (180 lb, 12 oz) (Polished finish: 84 kg (185 lb, 3 oz))
Width: 1,551 mm (61-1/16")
Height: 708 mm (27-7/8")
Depth: 736 mm (29")
Control Interface
Number of Keys: 88
Type: GrandTouch Keyboard: wooden keys (white only), synthetic ebony and ivory key tops, escapement
Touch Sensitivity: Hard2/Hard1/Medium/Soft1/Soft2
88-key Linear Graded Hammers: Yes
Number of Pedals: 3
Half Pedal: Yes
GrandTouch Pedals: Yes
Functions: Sustain, Sostenuto, Soft, Glide, Song Play/Pause, Style Start/Stop, Volume, etc
Type: TFT Color LCD (Touch Screen)
Size: 800 × 480 dots 7.0 inch
LCD Brightness: Yes
Touch Screen: Yes
Color: Yes
Score Display Function: Yes
Lyrics Display Function: Yes
Text Viewer Function: Yes
Languages: English, German, French, Spanish, Italian, Japanese
Panel Language: English
Cabinet
Key Cover Style: Folding
Music Rest: Yes
Music Clips: Yes
Voices
Tone Generation: Yamaha CFX, Bösendorfer Imperial
Binaural Sampling: Yes (“CFX Concert Grand” and “Bösendorfer Grand” Voice only)
Key-off Samples: Yes
Smooth Release: Yes
Virtual Resonance Modeling (VRM): Yes
Maximum Polyphony: 256
Preset Number of Voices: 1,315 Voices + 49 Drum/SFX Kits + 480 XG Voices
Featured Voices: 14 VRM Voices, 227 Super Articulation Voices
Custom Voice Edit: Yes
Compatibility XG, GS (for Song playback), GM, GM2
Effects
Reverb: 65 Preset + 30 User
Chorus: 106 Preset + 30 Use
Master Compressor: 5 Preset + 30 User
Master EQ: 5 Preset + 30 User
Part EQ: 27 Parts
Intelligent Acoustic Control (IAC): Yes
Stereophonic Optimizer: Yes
Insertion Effect: 322 Preset + 30 User
Variation Effect: 322 Preset + 30 User
Vocal Harmony: 54 Preset + 60 User
Functions Dual/Layers: Yes
Split: Yes
Accompaniment Styles
Number of Preset Styles: 525
Fingering: Single Finger, Fingered, Fingered On Bass, Multi Finger, AI Fingered, Full Keyboard, AI Full Keyboard
Style Control: INTRO x 3, MAIN VARIATION x 4, FILL x 4, BREAK, ENDING x 3
Custom Style Creator: Yes
One Touch Setting (OTS): 4 for each Style
Chord Looper: Yes
File Format Style: (SFF), Style File Format GE (SFF GE)
Songs
Number of Preset Songs: 50 Classics + 303 Lesson Songs + 60 Popular
Recording Number of Tracks: 16
Data Capacity approx. 3 MB / Song
Recording Function: Yes
Compatible Data Format Playback: SMF (Format 0 & 1), XF
Recording: SMF (Format 0)
Functions
Demo: Yes
Number of Buttons: 8
Control: Registration Sequence, Freeze
Playlist Number of Records: 2,500 Records
Lesson/Guide: Follow Lights, Any Key, Karao-Key, Your Tempo (with guide lamps)
Guide Lamp: Yes
Performance Assistant Technology (PAT): Yes
Piano Room: Yes
USB Audio Recorder Playback: WAV (44.1kHz, 16bit, stereo), MP3 (MPEG-1 Audio Layer-3)
Recording: WAV (44.1kHz, 16bit, stereo), MP3 (MPEG-1 Audio Layer-3)
USB Audio Time Stretch: Yes
Pitch Shift: Yes
Vocal Cancel: Yes
Metronome: Yes
Tempo Range: 5 – 500, Tap Tempo
Transpose: -12 – 0 – +12
Tuning: 414.8 – 440 – 466.8 Hz (approx. 0.2 Hz increments)
Scale Type: 9
Display Out: Yes (by using a commercially available USB display adaptor)
Bluetooth: Yes (Audio)
Storage and Connectivity
Storage Internal Memory approx. 2 GB
External Drives: USB Flash Drive
Connectivity Headphones: Standard stereo phone jack (x2)
Microphone: Mic/Line in (standard mono phone jack), Input volume
MIDI IN / OUT / THRU
AUXILIARY IN Stereo mini
AUX OUT L / L + R, R
AUX Pedal: Yes
USB TO DEVICE: Yes (x 2)
USB TO HOST: Yes
Amplifiers and Speakers
Amplifiers: (45 W + 20 W) × 2
Speakers: (16 cm + 2.5 cm (dome)) × 2
Power Consumption: 52W
Accessories: Headphones (HPH-150/HPH-100/HPH-50), Footswitches (FC4A/FC5), Foot controller (FC7), USB wireless LAN adaptor (UD-WL01)
