Control Interface
Number of Keys: 61
Type: FSX Keyboard
Initial Touch: Yes
Aftertouch: Yes (Channel After Touch)
Tone Generator: Motion Control Synthesis Engine AMW2: 128 Elements (max.), FM-X: 8 Operators, 88 Algorithms, AN-X: 3 Oscillators, 1 Noise
Maximum Polyphony: AWM2: 256 (max.; stereo/mono waveforms), FM-X: 128 (max.), AN-X: 16 (max.)
Multi Timbral Capacity: 16 Parts (internal), Audio Input Parts (A/D*1, USB*1) *1 stereo Part
Wave: Preset: 10 GB (when converted to 16-bit linear format), User: 3.7 GB
Performance: 3,369
Filter: 18 types
Effects: Reverb x 12 types, Variation x 88 types, Insertion A x 88 types*2, Insertion B x 89 types*3, Master Effect x 26 type, *2 A/D part insertion x 83 types *3 Part 2~16: 88 type, A/D part insertion x 83 types (Preset settings for parameters of each effect type are provided as templates) Master EQ (5 bands), 1st part EQ (3 bands), 2nd part EQ (2 bands)
Controllers: Master Volume, A/D Input Gain knob, Pitch Bend wheel, Modulation wheel, Ribbon Controller, Control Slider x 8, Knob x 8, Super knob, Display knob x 6, Portament knob, Data Dial, Assignable switch x 2, MSEQ trigger switch, Portamento switch, Keyboard hold switch, Ribbon Controller hold switch
Display: 7" TFT Color Wide VGA LCD touch screen, 512 x 64 Full-dot LCD
Connectors: [USB TO DEVICE] x 2, [USB TO HOST], MIDI [IN]/[OUT]/[THRU], FOOT CONTROLLER [1]/[2], FOOT SWITCH [SUSTAIN]/[ASSIGNABLE], OUTPUT (BALANCED) [L/MONO]/[R] (6.3 mm, Balanced TRS jacks), ASSIGNABLE OUTPUT (BALANCED) [L]/[R] (6.3 mm, Balanced TRS jacks), [PHONES] (6.3 mm, standard stereo phone jack), A/D INPUT [L/MONO]/[R] (6.3 mm, standard phone jacks)
Power Consumption: 36W
Accessories: AC Power cord, Quick Guide, Cubase AI Download Information, Expanded Softsynth Plugin for MONTAGE M Download Information
Live Sets: Preset: 128 and more, User: 2,048
Note Capacity: 1 Song/Pattern: Approx. 130,000 notes, Store area: Approx. 520,000 notes (Pattern); approx. 520,000 notes (Song)
Note Resolution: 480 ppq (parts per quarter note)
Tempo (BPM): 5 – 300
Sequence formats: MONTAGE original format, SMF formats 0, 1
Arpeggio: Parts: 8 Parts simultaneous (max.), Preset: 10,922 types or more, User: 256 types
Patterns: 128 patterns
Pattern tracks: 16 Sequence tracks
Pattern Recording type: Real time replace, Real time overdub
Songs: 128 songs
Song tracks: 16 Sequence tracks, Tempo track, Scene track
Song recording type: Real time replace, Real time overdub, Real time punch in/out
USB audio interface: [Sampling Frequency = 44.1 kHz] Input: 6 channels (3 stereo channels), Output: 32 channels (16 stereo channels) [Sampling Frequency = 44.1 kHz - 192 kHz] Input: 6 channels (3 stereo channels), Output: 8 channels (4 stereo channels)
Dimensions
Width: 1,037 mm (40-13/16")
Height: 131 mm (5-3/16")
Depth: 396 mm (15-9/16")
Weight: 15.3 kg (33 lbs., 12 oz.)
