Width: 1,326 mm (52-3/16”)
Height: 166 mm (6-9/16”)
Depth: 295 mm (11-5/8”)
Weight: 11.8 kg (26 lbs. 0 oz.)
Number of Keys: 88
Type: Graded hammer standard (GHS) keyboard, matte finish on black keys
Touch Sensitivity: Hard/medium/soft/fixed
Language: English
Piano Sound: Pure CF Sound Engine
Damper Resonance: Yes
Stereo Sustain Samples: Yes
Key-off Samples: Yes
String Resonance: Yes
Number of Polyphony (Max.): 192
Number of Voices: 24
Reverb: Yes (four types)
Intelligent Acoustic Control (IAC): Yes
Stereophonic Optimizer: Yes
Sound Boost: Yes
Table EQ: Yes
Dual/Layers: Yes
Split: Yes
Duo: Yes
Number of Preset Songs: 21 voice demo songs + 50 classics
Recording - Number of Songs: 1
Number of Tracks: 2
Data Capacity: 100 KB per song (approx. 11,000 notes)
Playback: SMF (format 0, format 1)
Recording: SMF (format 0)
Metronome: Yes
Tempo Range: 5 - 280
Transpose: -6 – 0 – +6
Tuning: 414.8 – 440.0 – 446.8 Hz
Rhythm: 20
DC IN: DC IN 12 V
Headphones: Standard stereo phone jack (x 2)
Sustain Pedal: Yes (Half pedal available with optional FC3A)
AUX OUT: [L/L+R] [R]
USB TO HOST: Yes
Pedal Unit: Yes (Optional)
Amplifiers: 7 W x 2
Speakers: 12 cm x 2 + 4 cm x 2
Power Supply: PA-150B or an equivalent recommended by Yamaha
Power Consumption: 9 W (using PA-150 AC power adaptor)
Auto Power Off: Yes
