Size/Weight
Dimensions:
Width: 37" (940 mm)
Height: 4-1/8" (104 mm)
Depth: 12-1/2" (317 mm)
Weight: 8 lb (4.0 kg, 13 oz) (not including batteries)
Control Interface
Keyboard Number of Keys 61
Display Type LCD display
Language English
Panel Language English
Voices
Tone Generation Tone Generating Technology AWM Stereo Sampling
Polyphony Number of Polyphony (Max.) 32
Preset Number of Voices 392 Voices + 18 drum/SFX kits
Effects
Types Reverb 9 types
Chorus 5 types
Master EQ 6 types
Ultra-Wide Stereo 3 types
Functions Panel Sustain Yes
Accompaniment Styles
Preset Number of Preset Styles 150
Fingering Smart Chord / Multi Finger
Style Control ACMP ON/OFF, SYNC START, START/STOP, INTRO/ENDING/rit, MAIN/AUTO FILL
Other Features One Touch Setting (OTS) Yes
Songs
Preset Number of Preset Songs 122 (including 10 Rhythm Tutor and 12 Chord Study Songs)
Recording Number of Songs 1
Number of Tracks 1
Data Capacity Approx. 300 notes
Functions
Lesson/Guide Lesson/Guide [1 LISTEN & LEARN], [2 TIMING], [3 WAITING]
Overall Controls Metronome Yes
Tempo Range 11 - 280
Transpose -12 to 0, 0 to +12
Tuning 427.0 - 440.0 - 453.0 Hz (approx.0.2Hz Increments)
Duo Yes
Miscellaneous PIANO Button Yes (Portable Grand Button)
Storage and Connectivity
Connectivity DC IN 12 V
Headphones Standard stereo phone jack (PHONES/OUTPUT)
Sustain Pedal Yes
AUX IN Stereo mini jack
Amplifiers and Speakers
Amplifiers 2.5 W + 2.5 W
Speakers 4.72" (12 cm) x 2
Power Supply
Power Consumption 6 W (When using PA-130 or an equivalent AC adaptor recommended by Yamaha)
Auto Power Off Function Yes
Power Supply Adaptors AC Adaptor PA-130 (Included), or an equivalent recommended by Yamaha
Batteries Six 1.5 V "AA" size alkaline (LR6), manganese (R6) or six 1.2 V "AA" size Ni-MH rechargeable batteries (HR6) (Not Included)
Accessories
Included Accessories Music Rest Yes
