Color: Black
Width: 1,017 mm (40-1/16")
Height: 139 mm (5-1/2")
Depth: 431 mm (17")
Weight: 11.6 kg (25 lb, 9 oz)
Packing Box:
Width: 1,174 mm (46-3/16")
Height: 246 mm (9-11/16")
Depth: 511 mm (20-1/8")
Number of Keys: 61
Type: Organ (FSB), Initial Touch
Touch Response: Normal, Soft1, Soft2, Hard1, Hard2
Joystick: Yes (Assignable)
Control Knobs: 2 (Assignable)
Assignable Buttons: 8 (A–F, 1–2)
Display Type: TFT Color Wide VGA LCD
Size: 800 x 480 dots (7 inch)
Touch Screen: Yes
Color: Yes
Language: English, German, French, Spanish, Italian, Chinese
Panel Language: English, Chinese
Tone Generating Technology: AWM Stereo Sampling
Number of Polyphony (Max.): 128
Preset Number of Voices: 1,377 Voices + 56 Drum/SFX Kits + 480 XG Voices
Featured Voices: 9 S.Articulation+, 252 S.Articulation, 55 OrganFlutes, 54 MegaVoice, 31 Sweet!, 87 Cool!, 131 Live!
Expansion Voice: Yes (approx. 1 GB)
Editing: Voice Set
Compatibility: XG, GM, GM2 (for Song Playback)
Part: Right1, Right2, Right3, Left
Effects Types:
Reverb: 59 Preset + 30 User
Chorus: 106 Preset + 30 User
DSP: 322 Preset + 30 User
Insertion Effect: Block 1-9: 322 Preset + 30 User
Master Compressor: 5 Preset + 30 User
Master EQ: 5 Preset + 30 User
Part EQ: 28 Parts
Others: Mic/Guitar effects: Noise Gate, Compressor, 3 Band EQ
Arpeggio: Yes
Number of Preset Styles: 450
Featured Styles: 410 Pro Styles, 37 Session Styles, 3 Free Play Styles
Fingering: Single Finger, Fingered, Fingered On Bass, Multi Finger, AI Fingered, Full Keyboard, AI Full Keyboard, Smart Chord
Style Control: INTRO x 3, MAIN VARIATION x 4, FILL x 4, BREAK, ENDING x 3
Compatibility: Style File Format (SFF), Style File Format GE (SFF GE)
Expansion Style: Yes (Internal Memory)
Chord Looper: Yes
Style Section Reset: Yes
Style Section Change Timing: Yes
Style Section Time Signature: Yes
Style Dynamics Control: Yes (with knobs / pedal)
One Touch Setting (OTS): 4 for each Style
Number of Preset Songs: 1 Demo Song, 2 Preset Songs
Number of Songs: Unlimited (depends on the drive capacity)
Number of Tracks: 16
Data Capacity: Approx. 3 MB/Song
Recording Function: Quick Recording, Multi Recording, Step Recording
Playback: SMF (Format 0 & 1), XF
Recording: SMF (Format 0)
Number of Multi Pad Banks: 349 banks x 4 Pads
Audio Link: Yes
Voices:
Harmony/Echo: Yes (with Arpeggio)
Panel Sustain: Yes
Mono/Poly: Yes
Voice Information: Yes
Style Creator: Yes
OTS Information: Yes
Score Display Function: Yes
Lyrics Display Function: Yes
Multi Pad Creator: Yes
Number of Buttons: 8
Control: Registration Sequence, Freeze
Number of Records: 2,500 (max.) Records per Playlist file
Search: Registration Bank
Recording Time (max.): 80 minutes/Song
Recording: WAV (44.1 kHz, 16-bit, stereo), MP3 (44.1 kHz, 128/256/320 kbps, stereo)
Playback: WAV (44.1 kHz, 16-bit, stereo), MP3 (44.1/48.0 kHz, 64–320 kbps and VBR mono/stereo)
Time Stretch: Yes
Pitch Shift: Yes
Vocal Cancel: Yes
Demonstration: Yes
Metronome: Yes
Tempo Range: 5 - 500, Tap Tempo
Transpose: -12 – 0 – +12
Tuning: 414.8 – 440 – 466.8 Hz
Octave Button: Yes
Scale Type: 9 types
Sub Scale Setting: Yes
Direct Access: Yes
Text Display Function: Yes
Wallpaper Customization: Yes
Internal Memory: Yes (approx. 1 GB)
External Drives: USB flash drive
Headphones: Standard stereo phone jack
Microphone: Yes (Microphone/Guitar)
MIDI: IN/OUT
AUX IN: Stereo mini jack
LINE OUT: MAIN OUTPUT (L/L+R, R)
FOOT PEDAL: 1 (SUSTAIN), 2 (ARTICULATION 1), Function assignable
USB TO DEVICE: Yes
USB TO HOST: Yes
Amplifiers: 15 W x2
Speakers: 13 cm x 2 + 5 cm x 2
