MAXIMUM NUMBER OF SIMULTANEOUS EFFECTS 6 effects + 1 pedal effect
USER PATCH MEMORIES 300
USER PATCH MEMORIES 44.1 kHz
A/D CONVERSION 24-bit 128× oversampling
D/A CONVERSION 24-bit 128× oversampling
SIGNAL PROCESSING 32-bit
FREQUENCY RESPONSE 20 Hz – 20 kHz (+0.5 dB/−0.5 dB) (10kΩ load)
DISPLAY 256×128 dot-matrix LCD
INPUTS INPUT Standard mono phone jack
Rated input level: −20 dBu
Input impedance (line): 470 kΩ
AUX IN Stereo mini jack
Rated input level：–10 dBu
Input impedance (line)：10 kΩ
OUTPUTS LEFT/RIGHT Standard mono phone jack
Maximum output level: +9.3 dBu (when output impedance 10 kΩ or higher)
PHONES Stereo mini jack
Maximum output power: 20 mW + 20 mW (into 32Ω load)
INPUT S/N 122 dB
NOISE FLOOR (RESIDUAL NOISE) LEFT/RIGHT –99.3 dBu
PHONES: –99.3 dBu
CONTROL INPUT FP02M input (G2 FOUR only)
POWER AC adapter 9V DC 500mA center negative (ZOOM AD-16)
• USB bus power is supported.
USB USB 2.0 Type-C port (use cable that supports Type-C)
Handy Guitar Lab: USB 1.1 Full Speed
Audio interface: USB 2.0 Full Speed,
44.1kHz, 32-bit, 2-in/2-out
• Use a USB cable that supports data transfer.
DIMENSIONS G2 FOUR 145 mm (D) × 184 mm (W) × 71 mm (H)
G2X FOUR 150 mm (D) × 274 mm (W) × 71 mm (H)
G2 FOUR 707 g
G2X FOUR 951g
