Wattage: Multi-Watt™ 2, 10, 20, 30, or 40
Channels & Modes: 1 Channel
Mode Voicings styles: Single Channel with two Inputs: Normal Input = Clean to Overdrive Low Input = Clean
Graphic Eq Reverb Fx Solo: Reverb
Foot switchable Functions: Reverb (Footswitch & Cable sold seperately)
Speakers Impedance: 1 - 8 Ohm Jensen Blackbird ALNICO 40 / Total Load = 8 Ohms
Weight: 46.4 Lbs.
Dimensions: 19 1/4" H x 22 3/4" W x 10 3/8" D
Available Formats: Head & 1x12 Combo
Amp Type: Tube
Rectifier Type: Silicon Diodes
Preamp Tubes: 5x Mesa 12AX7 & 1x Mesa 12AT7
Power Amp Tubes: 4x Mesa 6V6
Wattages Quick Reference: 2, 10, 20, 30 or 40 Watts - See Power Amp Details for more information
Power Amp Details Class Wattage: Mesa's Patented Incremental Multi-Watt™ (Patent 9,917,560) Power Amp, featuring Duo-Class™ (Patent 7,173,488) and Dyna-Watt technologies, provides five power, two operating-classes and three wiring configuration options via one 5-Way Power Switch - Choose from the following power options: 40 Watt - 4x6V6 Class A/B Pentode 30 Watts - 2x6V6 Class A/B Triode + 2x6V6 Class A/B Pentode 20 Watts - 2x6V6 Class A/B Pentode 10 Watts - 2x6V6 Class A/B Triode 2 Watts - 1x6V6 Triode + 1x6V6 Pentode, Single-Ended Class A Parallel More information on Dyna-Watt Power can be found in the Owners Manual, which is available in the Support Section of this website.
Number Of Style Modes: Two (Inputs)
Number Of Style Modes Per Channel: Two (Inputs)
Channel Controls: Gain, Treble, Mid, Bass, Presence, Reverb, and Master
Reverb Effects Bypass Options: All-Tube, Spring Reverb
Effects Loop Bypass Options: Fully Buffered Series FX Loop
External Switching Jack Options And/or Midi: External Switching Jack for Reverb On/Off (Reverb Footswitch and Cable sold seperately)
Speaker Outputs: One 8 Ohm and Two 4 Ohm
Cabinet Material: Marine Grade, Baltic Birch
Standard Finish Options (no extra cost): Choice of Cream Bronco Vinyl, Cream/Tan Weave Jute Grille, Brown Handle & Corners or Black Bronco or Black Taurus Vinyl, Black Jute Grille, Black Handle & Corners
Speakers Impedance: 1 - 8 Ohm Jensen Blackbird ALNICO 40 / Total Load = 8 Ohms
Casters: Optional - Track-Loc™ Removable Casters
Extra Features: Vintage-Inspired Size for Tone & Portability
Weight: 46.4 Lbs.
Height: 19 1/4"
Width: 22 3/4"
Depth: 10 3/8"
