Wattage: Full Power (40W Clean/60W Max) or Half Power (20W Clean/28W Max) Selectable (Global)
Channels & Modes: 2 Channels / 3 Mode Channel Cloning™
Mode Voicings styles: Ch. 1 = Clean, Drive or HI (Channel Cloning™) Ch. 2 = Clean, Drive or HI (Channel Cloning™)
Graphic Eq Reverb Fx Solo: Reverb & FX Loop
Foot switchable Functions: Ch. 1/2
Speakers Impedance: 1 - 8 Ohm Celestion Custom 90 / Total Load = 8 Ohms
Weight: 45 Lbs.
Dimensions: 17 7/8" H x 22 3/4" W x 10 1/8" D
Available Formats: Head & 1x12 Combo
Amp Type: Tube
Rectifier Type: Silicon Diodes
Rectifier Tubes: n/a
Variac PowerSwitch: n/a
Preamp Tubes: 5x Mesa 12AX7
Power Amp Tubes: 2x Mesa 6L6
Maintenance Free Fixed Bias: Yes
Wattages Quick Reference: 40 Watts Clean/60 Watts Max or 20 Watts Clean/28 Watts Max via single, global Full/Half Power Switch - See Power Amp Details for more information
Built In Power Amp Attenuation: n/a
Power Amp Details Class Wattage: MESA's proprietary Dyna-Watt™, Class A/B Power Amp with a single, global Full/Half Power Switch - Each setting features a different wiring configurations, Pentode or Triode respectively. Choose from 2 power tubes operating in Class A/B Triode for lush harmonics and a sweet, liquid feel at lower volumes, producing 20 (Clean)/28 (Max) Watts or; 2 tubes operating in Class A/B Pentode for maximum power, punch and clarity, producing 40 (Clean)/60 (Max) Watts. More information on Dyna-Watt Power can be found in the Owners Manual, which is available in the Support Section of this website.
Number Of Style Modes: Three
Number Of Style Modes Per Channel: Three (Channel Cloning™)
Channel Controls: Each Channel features Independent 3-Position Channel Cloning™ Mode Switch, Gain, Treble, Mid, Bass, Presence, Reverb, and Master
Graphic Eq And/or Contour: n/a
Reverb Effects Bypass Options: All-Tube, Spring Reverb with Independent Channel Controls
Effects Loop Bypass Options: Fully Buffered Series FX Loop
Global Output Level Control: n/a
Global Solo Level Control: n/a
True Bypass Options: n/a
External Switching Jack Options And/or Midi: External Switching Jack for Reverb On/Off (Reverb Footswitch and Cable sold seperately)
Speaker Outputs: One 8 Ohm and Two 4 Ohm
Cabinet Simulation Direct Live recording Output: n/a
Internal Amp Load For SpeakerLess Performance: n/a
Headphone Output: n/a
Slave Output: n/a
Extra Features: Reverb Controls located on front panel
Cabinet Material: Marine Grade, Baltic Birch
Standard Finish Options (no extra cost): Choice of Black Bronco or Black Taurus Vinyl with Tinsel or Black Jute Grille
Custom Finish Options: See Custom Finish Gallery
Speakers Impedance: 1 - 8 Ohm Celestion Custom 90 / Total Load = 8 Ohms
Casters: Optional - Track-Loc™ Removable Casters
Extra Features: Vintage-Inspired Size for Tone & Portability
Weight: 45 Lbs.
Height: 17 7/8"
Width: 22 3/4"
Depth: 10 1/8"
