Maximum number of simultaneous effects: 2 effects
User patch memories: 250
Sampling frequency: 44.1 kHz
A/D conversion: 24-bit 128× oversampling
D/A conversion: 24-bit 128× oversampling
Signal processing: 32-bit
Frequency response: 20 Hz – 20 kHz (+0.5 dB/−0.5 dB) (when 10kΩ load)
Display: 160 × 128 dot-matrix LCD
Input: Standard mono phone jack
Rated input level: −20 dBu
Input impedance (line): 470 kΩ
Outputs L/R: Standard mono phone jacks
Maximum output level: +7.2 dBu (when output impedance 10 kΩ or higher)
Input S/N :122 dB
Noise floor (residual noise) L/R –100 dBu
Power AC adapter 9V DC 500mA center negative (ZOOM AD-16)
2 AA batteries Alkaline, Lithium or rechargeable NiMH batteries
• USB bus power is supported.
Estimated operation times using batteries: Alkaline batteries About 7 hours
NiMH batteries: (1900 mAh) About 6.5 hours
Lithium batteries: About 14 hours
• These values are approximate. • Battery operation times were determined using in-house testing methods. They will vary greatly according to use conditions.
USB Port USB 2.0 Type-C
Supported cable type: Type-C
Handy Guitar Lab USB1.1 Full Speed
Dimensions: 133 mm (D) × 79 mm (W) × 61 mm (H)
Weight: 346 g (excluding batteries) 393 g (including batteries)
Note: 0 dBu = 0.775 VMaximum number of simultaneous effects: 2 effects
User patch memories: 250
Sampling frequency: 44.1 kHz
A/D conversion: 24-bit 128× oversampling
D/A conversion: 24-bit 128× oversampling
Signal processing: 32-bit
Frequency response: 20 Hz – 20 kHz (+0.5 dB/−0.5 dB) (when 10kΩ load)
Display: 160 × 128 dot-matrix LCD
Input: INPUT Standard mono phone jack
Rated input level: −20 dBu
Input impedance (line): 470 kΩ
Outputs L/R: Standard mono phone jacks
Maximum output level: +7.2 dBu (when output impedance 10 kΩ or higher)
Input S/N: 122 dB
Noise floor (residual noise): L/R –100 dBu
Power: AC adapter 9V DC 500mA center negative (ZOOM AD-16)
2 AA batteries Alkaline, Lithium or rechargeable NiMH batteries
USB Port USB 2.0 Type-C
Supported cable type: Type-C
Dimensions: 133 mm (D) × 79 mm (W) × 61 mm (H)
Weight: 346 g (excluding batteries) 393 g (including batteries)
